This right-angle gearbox features a compact 90 x 90 mm design, with a 19mm input shaft diameter and a 4:1 gear ratio. Specifically designed for servo motor applications, it provides a 90-degree orientation between the high-speed input shaft and the low-speed output shaft.

Its compact structure allows it to fit into tight installation spaces while maintaining reliable performance, making it an ideal solution for applications where the motor and driven components need to be positioned at a right angle, such as conveyors, automation systems, and other industrial machinery.

Gearbox Specifications

  • Part Number: RTG90-G4
  • Gearbox Type: Right Angle Planetary
  • Gear Material: Alloy Steel
  • Gear Ratio: 4:1
  • Efficiency: 96%
  • Backlash at No-load: <=10arc-min
  • Max.Permissible Torque: 80Nm(708.06lb-in)
  • Moment Permissible Torque: 160Nm(1416.12lb-in)
  • Gearbox Matching Motor's Input Shaft Length: 22-41mm
  • Shaft Maximum Axial Load: 800N
  • Shaft Maximum Radial Load: 1000N
  • Rated Input Speed: 3000rpm
  • Max. Input Speed: 6000rpm
  • Noise: <=55dB
  • Waterproof Rating: IP54
  • Lifetime: 20000hours
  • Working Temperature: -20~150℃(-4~302°F)

Physical Specifications

  • Frame Size: 90 x 90mm
  • Gearbox Length: 149.5mm
  • Output Shaft Type: Key way
  • Output Shaft Diameter: Φ20mm
  • Output Shaft Length: 40mm
  • Input Shaft Diameter: Φ19mm
  • Input Shaft Length: 22~41mm

Other optional reduction ratios.

7 : 1
16 : 1
25 : 1
28 : 1
35 : 1
40 : 1
70 : 1
Physical Specification
Backlash at No-load <=10 arcmin
Frame Size(mm) 90 x 90
Gear Material Alloy Steel
Gear Ratio(xx:1) 4
Gearbox Length(mm) 149.5
Gearbox Type Right Angle Planetary
Input Shaft Diameter(mm) 19
Input Shaft Length(mm) 22 - 41
IP Rating 54
Matching Motor Size Frame 80/90 Servo Motor
Output Shaft Diameter(mm) 20
Output Shaft Length(mm) 40
Output Shaft Type Keyway
Product Series RTG
