BD600 Series VFD 10HP/15HP 7.5/11KW 18/24A Three Phase 380V Variable Frequency Drive

BD600 Series VFD 10HP/15HP 7.5/11KW 18/24A Three Phase 380V Variable Frequency Drive - BD600-7R5G-011P-4 | StepperOnline UK
BD600-7R5G-011P-4 Discontinued

This product has been discontinued and is no longer available for purchase. Please contact us for a replacement.

Question

Downloads

BD600_Series_Inverter_User_Manual.pdfPDF · 3.5MB
Same series
ModelPriceStock
1-CL57Y-S12 Discontinued—————
1-CL57Y-S20 Discontinued—————
1-CL57Y-S30A Discontinued—————
1-CLYS20 Discontinued—————
1-CLYS30 Discontinued—————
1-CLYS30-1M5 Discontinued—————
1-CLYS30S-V20 Discontinued—————
1-CLYS40 Discontinued—————
1-DM542T-24HS34 Discontinued—————
1-DM542T-24HS39 Discontinued—————
1-DM556S-24HS39 Discontinued—————
11C13S0754ED3-013RS Discontinued—————
11E13S0754ED2-100RS Discontinued—————
11E18S0754ED2-101RS Discontinued—————
11E18S0754FD3-250RS Discontinued—————
11E18S0754GD3-250RS Discontinued—————
11E20S0674AA2-100RS Discontinued—————
11E20S0674ED2-100RS Discontinued—————
11HS12-0674D2-PG27 Discontinued—26.85Economy Planetary——
11HS12-0674S-PG100 Discontinued—99.548Economy Planetary——
11HS20-0674D-PG14-AR3 Discontinued—13.73Economy Planetary——
11HS20-0714S-PG100 Discontinued—99.05Economy Planetary——
11N13S0754AA2-100RS Discontinued—————
11N13S0754QE2-150RS Discontinued—————
11N18S0754ED3-250RS Discontinued—————
11N20S0674AA2-100RS Discontinued—————
14E13S0574JE3-150RS Discontinued—————
14E13S0574QE3-150RS Discontinued—————
14E17S0914JE3-250RS Discontinued—————
14E17S0914QE3-250RS Discontinued—————
View all in category
BD600 Series VFD 10HP/15HP 7.5/11KW 18/24A Three Phase 380V Variable Frequency Drive
This VFD with two types of power G: 10HP(7.5Kw)/P: 15HP(11Kw), and three phase 380V input voltage. T... Read More
0 reviews • Write a review
Add to Wish List Compare this Product
Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Read more
Choose a Local Warehouse, Get More Benefits!
UK customers: choose the UK warehouse for faster delivery, easier after-sales support and no customs clearance. The China warehouse is open to all countries.

This VFD with two types of power G: 10HP(7.5Kw)/P: 15HP(11Kw), and three phase 380V input voltage. The BD600 series is a high performance Vector Control Variable Frequency Drive(VFD), they are widely used in application of: Metal processing, CNC machine tools, Wire drawing machines, Boiler blower, Induced draft fan, Coal mine underground exhaust fan, Municipal engineering, Counter-cyclone, Centrifugal fan, Circulating water pump, Make-up water pump, Oil field injection water pump, Oil transfer pump, music fountain, Papermaking equipment, Chemical industry, Pharmaceutical industry, Textile industry, etc.


Key Specification

  • Input Voltage: 3-Phase 380VAC±15%
  • Input Frequency: 47～63Hz
  • Input Current: G: 20.5A/P: 26A
  • Input Power factor: ≥95%
  • Power: G: 10HP(7.5Kw)/P: 15HP(11Kw)
  • Output Current: G: 18A/P: 24A
    Operating Environment
    Store Temperature-20℃～60℃
    Variable Frequency Drive Specification
    Acceleration and Deceleration ModeLine or S-curve, 4 types of acceleration/deceleration time with the range of 0.0~6500.0s
    Automatic Voltage Regulation(AVR)Automatically maintain a constant output voltage when the voltage of electricity grid changes
    Built-in PIDBuilt-in PID control to easily realize the closed loop control for the process parameters (such as a pressure, temperature, flow, etc.)
    Carrier Frequency0.5 to 16.0kHz; automatically adjust carrier frequency according to the load characteristics
    Common DC BusMultiple inverters can use a common DC bus(Common DC bus function)
    Control ModesV/F control, non-PG vector control(SVC), PG vector control(FVC)
    Cooling ModeForced air-cooling
    DC BrakeSupports starting and stopping DC brake
    Fixed Length ControlSetting length control
    Frequency Reference SourceDigital, analog, pulse frequency, serial communication, multi-step speed, simple PLC and PID The combination of multi-modes and the different modes can be switched
    Frequency Resolution0.01Hz(Digital setting); maximum frequency x 0.025%(Anolog setting)
    Humidity & Temperature90%RH or less (no-condensation), -10℃～40℃.Inverter will be derated if ambient temperature exceeds 40℃
    Input Current20.5A(3PH)
    Input Frequency47 - 63Hz
    Input Power factor≥95%
    Input Terminalsa. Supports high speed pulse input, b. 1 Analog voltage input 0~10VDC, c. 2 Voltage input 0~10VDC or current input 0~20mA
    Input Voltage3PH 380VAC
    Jogging Control0.0Hz~50.00Hz(Jog frequency range); 0~6500.0s(Jog Acc/Dec time)
    Operation Command ModeKeypad control, Terminal control, Serial communication control
    Output Current18.0A
    Output Power10HP / 7.5KW
    Output Terminalsa. 1 Open collector output, it can be extended to 1 high speed pulse output, b. 2 Relay outputs, c. 2 Analog output: voltage output 0~10VDC or current output 0~20mA
    Overload CapacityG type: 150% rated current 60s, 180% rated current 3s; P type: 120% rated current 60s, 150% rated current 3s
    Protection ClassIP20
    Simple PLC & Multi-step Speed OperationBuilt-in PLC or control terminal, 16 steps speed can be set
    Speed Adjusting Range1:100(SVC), 1:1000(FVC)
    Speed Control Accuracy±0.5%(SVC), ±0.02%(FVC)
    Start TorqueG type: 0.5Hz/150%(SVC), 0Hz/180%(FVC); P type: 0.5Hz/100%
    Store Environment≤1000M, indoor(no corrosive gas and liquid)
    Timing Control0~6500min(Setting time range)
    Torque BoostAutomatic torque boost; manual torque boost 0.1~30%
    Traverse ControlMultiple triangular pulse frequency control(Traverse control function)
    V/F ControlLine, Multiple point, square V/F curve, V/F separation
    VibrationUnder 20Hz 9.8m/s(1G), Over 20Hz5.88m/s(0.6G)
