Name: 40W 110VAC 60Hz 51.6RPM 5.07Nm(717.97oz.in) Flange 90mm Spur Gearbox Single-phase AC Induction Motor
Brand: STEPPERONLINE
SKU: 5IK40GN-AT/5GN30K
Price: 34.69 GBP
Availability: BackOrder

40W 110VAC 60Hz 51.6RPM 5.07Nm(717.97oz.in) Flange 90mm Spur Gearbox Single-phase AC Induction Motor - 5IK40GN-AT/5GN30K | StepperOnline UK

5IK40GN-AT/5GN30K

Output Shaft TypeKeyway

Input Voltage(V)1PH 110VAC

Frame Size(mm)90 x 90

Current(A)0.66

Question

Downloads

5IK40GN-XXT_5GNXXK_manual.pdfPDF · 2.22MB

Same series

Model	Output Shaft Type	Input Voltage(V)	Frame Size(mm)	Current(A)	Price	Stock
5IK120GU-S/S3FT/5GU20KB	Keyway	3PH 220VAC/380VAC	90 x 90	0.60,0.70,0.42,0.40	£45.62	In stock
5IK120GU-S/S3FT/5GU30KB	Keyway	3PH 220VAC/380VAC	90 x 90	0.60,0.70,0.42,0.40	£45.62	In stock
5IK120GU-S/S3FT/5GU3KB	Keyway	3PH 220VAC/380VAC	90 x 90	0.60,0.70,0.42,0.40	£41.74	In stock
5IK120GU-S/S3FT/5GU50KB	Keyway	3PH 220VAC/380VAC	90 x 90	0.60,0.70,0.42,0.40	£45.62	In stock
5IK120GU-S/S3FT/5GU5KB	Keyway	3PH 220VAC/380VAC	90 x 90	0.60,0.70,0.42,0.40	£41.74	In stock
5IK40GN-AT/5GN100K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40GN-AT/5GN10K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40GN-AT/5GN15K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40GN-AT/5GN200K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40GN-AT/5GN20K	Keyway	1PH 110VAC	90 x 90	0.66	£34.69	In stock
5IK40GN-AT/5GN30K	Keyway	1PH 110VAC	90 x 90	0.66	£34.69	In stock
5IK40GN-AT/5GN3K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40GN-AT/5GN50K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40GN-AT/5GN5K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40GN-CT/5GN100K	Keyway	1PH 220VAC	90 x 90	0.35	£36.13	In stock
5IK40GN-CT/5GN10K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40GN-CT/5GN15K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40GN-CT/5GN200K	Keyway	1PH 220VAC	90 x 90	0.35	£36.13	In stock
5IK40GN-CT/5GN20K	Keyway	1PH 220VAC	90 x 90	0.35	£34.69	In stock
5IK40GN-CT/5GN30K	Keyway	1PH 220VAC	90 x 90	0.35	£34.69	In stock
5IK40GN-CT/5GN3K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40GN-CT/5GN50K	Keyway	1PH 220VAC	90 x 90	0.35	£36.13	In stock
5IK40GN-CT/5GN5K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40GN-S/S3T/5GN100K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£36.13	In stock
5IK40GN-S/S3T/5GN10K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£33.39	In stock
5IK40GN-S/S3T/5GN10K-SALE	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£33.92	In stock
5IK40GN-S/S3T/5GN15K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£33.39	In stock
5IK40GN-S/S3T/5GN200K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£36.13	In stock
5IK40GN-S/S3T/5GN20K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£34.69	In stock
5IK40GN-S/S3T/5GN30K	Keyway	3PH 220VAC/380VAC	90 x 90	0.32,0.28,0.18,0.16	£34.69	In stock

View all in category

40W 110VAC 60Hz 51.6RPM 5.07Nm(717.97oz.in) Flange 90mm Spur Gearbox Single-phase AC Induction Motor

This 90x90mm single-phase AC induction gear motor is powered by 110VAC and has a gear ratio of 30, a... Read More

0 reviews • Write a review

from

£34.69

5 + £33.76

10 + £32.87

50 + £32.03

100 + £31.24

Click country for live stock

Dispatches from

China

Qty

Add to Cart

Add to Wish List Compare this Product

Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Ships within 24 hours!

Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Choose a Local Warehouse, Get More Benefits!

UK customers: choose the UK warehouse for faster delivery, easier after-sales support and no customs clearance. The China warehouse is open to all countries.

This 90x90mm single-phase AC induction gear motor is powered by 110VAC and has a gear ratio of 30, a torque of 5.07Nm(717.97oz.in) and a speed of 51.6rpm. The simple brushless structure, high reliability, relatively high efficiency and long service life make it an excellent cost-effective choice for constant speed applications like industrial equipments, household appliances, power supply systems, transportation, mechanical equipment, etc.

Electrical Specifications

P/N: 5IK40GN-AT/5GN30K
Gearbox Type: Spur Gearbox
Output Power: 40W
Voltage: 1PH 110VAC
Frequency: 60Hz
Current: 0.66A
Gear Ratio: 30:1
Speed: 51.6rpm
Torque: 5.07Nm(717.97oz.in)
Capacitor: 10.0μF/250VAC

Physical Specifications

Frame Size: 90x90mm
Body Length: 165mm
Shaft Type: Keyway
Shaft Diameter: Φ12mm
Shaft Length: 32mm
Weight: 3.53kg

Wiring

Electrical Specification
Current(A)	0.66
Frequency(Hz)	60
Input Voltage(V)	1PH 110VAC
Output Power(W)	40
Speed(rpm)	51.6
Torque(Nm)	5.07
Physical Specification
Frame Size(mm)	90 x 90
Gear Ratio(xx:1)	30
Gearbox Type	Spur Gearbox
Output Shaft Type	Keyway
