6IK200GU-S/S3FT/6GU30RT
Output Shaft TypeKeyway
Input Voltage(V)3PH 220VAC/380VAC
Frame Size(mm)104 x 104
Current(A)1.17,0.98,0.66,0.57
Question

Downloads

6IK200GU-XXFT_6GUXXRX_manual.pdfPDF · 2.31MB
Same series
ModelOutput Shaft TypeInput Voltage(V)Frame Size(mm)Current(A)PriceStock
6IK200GU-CFT/6GU100RCHollow1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-CFT/6GU100RTKeyway1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-CFT/6GU10RCHollow1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU10RTKeyway1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU15RCHollow1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU15RTKeyway1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU180RCHollow1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-CFT/6GU180RTKeyway1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-CFT/6GU20RCHollow1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU20RTKeyway1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU30RCHollow1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU30RTKeyway1PH 220VAC104 x 1041.3£82.76In stock
6IK200GU-CFT/6GU50RCHollow1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-CFT/6GU50RTKeyway1PH 220VAC104 x 1041.3£84.34In stock
6IK200GU-S/S3FT/6GU100RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
6IK200GU-S/S3FT/6GU100RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
6IK200GU-S/S3FT/6GU10RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU10RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU15RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU15RC-SALEHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.07In stock
6IK200GU-S/S3FT/6GU15RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU180RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
6IK200GU-S/S3FT/6GU180RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
6IK200GU-S/S3FT/6GU180RT-SALEKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.92In stock
6IK200GU-S/S3FT/6GU20RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU20RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU30RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU30RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£82.76In stock
6IK200GU-S/S3FT/6GU50RCHollow3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
6IK200GU-S/S3FT/6GU50RTKeyway3PH 220VAC/380VAC104 x 1041.17,0.98,0.66,0.57£84.34In stock
View all in category
200W 220/380VAC 45RPM 31.00Nm(4389.96oz.in) Flange 104mm Right Angle Gearbox Keyway Shaft Three-phase AC Induction Motor
This 104x104mm keyway shaft three-phase AC induction gear motor can be powered by either 220VAC or 3... Read More
0 reviews • Write a review
from
£82.76
5 + £80.53
10 + £78.43
50 + £76.43
100 + £74.53

Click country for live stock

Add to Cart
Add to Wish List Compare this Product
Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Read more
Ships within 24 hours!
Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.
Choose a Local Warehouse, Get More Benefits!
UK customers: choose the UK warehouse for faster delivery, easier after-sales support and no customs clearance. The China warehouse is open to all countries.

This 104x104mm keyway shaft three-phase AC induction gear motor can be powered by either 220VAC or 380VAC and has a gear ratio of 30. The right angle gearboxes are compact in size, run smoothly and can handle high torques. The simple brushless structure, high reliability, relatively high efficiency and long service life make it an excellent cost-effective choice for constant speed applications like industrial equipments, household appliances, power supply systems, transportation, mechanical equipment, etc.

Electrical Specifications

  • P/N: 6IK200GU-S/S3FT/6GU30RT
  • Gearbox Type: Right Angle Gearbox
  • Output Power: 200W
  • Voltage: 3PH 220VAC/3PH 380VAC
  • Frequency: 50/60Hz
  • Current(220VAC): 1.17A(50Hz)/0.98A(60Hz)
  • Current(380VAC): 0.66A(50Hz)/0.57A(60Hz)
  • Gear Ratio: 30:1
  • Speed: 45rpm
  • Torque: 31.00Nm(4389.96oz.in)

Physical Specifications

  • Frame Size: 104x104mm
  • Body Length: 331mm
  • Shaft Type: Keyway
  • Shaft Diameter: Φ20mm
  • Shaft Length: 48mm
  • Weight: 9.42kg

Wiring

Electrical Specification
Current(A) 1.17,0.98,0.66,0.57
Frequency(Hz) 50,60
Input Voltage(V) 3PH 220VAC/380VAC
Output Power(W) 200
Speed(rpm) 45
Torque(Nm) 31
Physical Specification
Frame Size(mm) 104 x 104
Gear Ratio(xx:1) 30
Gearbox Type Right Angle Gearbox
Output Shaft Type Keyway
