Name: 120W 220VAC 50Hz 3-45RPM 19.00Nm(2690.59oz.in) Flange 90mm Right Angle Gearbox Single-phase AC Variable Speed Motor
Brand: STEPPERONLINE
SKU: 5IK120RGU-CF/5GU30RC
Price: 60.88 GBP
Availability: BackOrder

120W 220VAC 50Hz 3-45RPM 19.00Nm(2690.59oz.in) Flange 90mm Right Angle Gearbox Single-phase AC Variable Speed Motor - 5IK120RGU-CF/5GU30RC | StepperOnline UK

5IK120RGU-CF/5GU30RC

Output Shaft TypeHollow

Input Voltage(V)1PH 220VAC

Frame Size(mm)90 x 90

Current(A)0.87

Question

Downloads

5IK120RGU-XF_5GUXXRX_Manual.pdfPDF · 1.7MB

Same series

Model	Output Shaft Type	Input Voltage(V)	Frame Size(mm)	Current(A)	Price	Stock
5IK120RGU-CF/5GU15KB	Keyway	1PH 220VAC	90 x 90	0.87	£43.90	In stock
5IK120RGU-CF/5GU15RC	Hollow	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU15RT	Keyway	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU180RC	Hollow	1PH 220VAC	90 x 90	0.87	£62.47	In stock
5IK120RGU-CF/5GU180RT	Keyway	1PH 220VAC	90 x 90	0.87	£62.47	In stock
5IK120RGU-CF/5GU200KB	Keyway	1PH 220VAC	90 x 90	0.87	£47.64	In stock
5IK120RGU-CF/5GU20KB	Keyway	1PH 220VAC	90 x 90	0.87	£45.62	In stock
5IK120RGU-CF/5GU20RC	Hollow	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU20RT	Keyway	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU30KB	Keyway	1PH 220VAC	90 x 90	0.87	£45.62	In stock
5IK120RGU-CF/5GU30RC	Hollow	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU30RT	Keyway	1PH 220VAC	90 x 90	0.87	£60.88	In stock
5IK120RGU-CF/5GU3KB	Keyway	1PH 220VAC	90 x 90	0.87	£41.74	In stock
5IK120RGU-CF/5GU50KB	Keyway	1PH 220VAC	90 x 90	0.87	£45.62	In stock
5IK120RGU-CF/5GU50RC	Hollow	1PH 220VAC	90 x 90	0.87	£62.47	In stock
5IK120RGU-CF/5GU50RT	Keyway	1PH 220VAC	90 x 90	0.87	£62.47	In stock
5IK120RGU-CF/5GU5KB	Keyway	1PH 220VAC	90 x 90	0.87	£41.74	In stock
5IK40RGN-A/5GN100K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40RGN-A/5GN10K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40RGN-A/5GN15K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40RGN-A/5GN200K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40RGN-A/5GN20K	Keyway	1PH 110VAC	90 x 90	0.66	£34.69	In stock
5IK40RGN-A/5GN30K	Keyway	1PH 110VAC	90 x 90	0.66	£34.69	In stock
5IK40RGN-A/5GN3K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40RGN-A/5GN50K	Keyway	1PH 110VAC	90 x 90	0.66	£36.13	In stock
5IK40RGN-A/5GN5K	Keyway	1PH 110VAC	90 x 90	0.66	£33.39	In stock
5IK40RGN-C/5GN100K	Keyway	1PH 220VAC	90 x 90	0.35	£36.13	In stock
5IK40RGN-C/5GN10K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40RGN-C/5GN15K	Keyway	1PH 220VAC	90 x 90	0.35	£33.39	In stock
5IK40RGN-C/5GN200K	Keyway	1PH 220VAC	90 x 90	0.35	£36.13	In stock

View all in category

120W 220VAC 50Hz 3-45RPM 19.00Nm(2690.59oz.in) Flange 90mm Right Angle Gearbox Single-phase AC Variable Speed Motor

This 90x90mm hollow shaft single-phase AC motor with adjustable speed control is operated with 220VA... Read More

0 reviews • Write a review

from

£60.88

5 + £59.24

10 + £57.69

50 + £56.22

100 + £54.83

Click country for live stock

Dispatches from

China

Qty

Add to Cart

Add to Wish List Compare this Product

Easy Returns

Return within 30 days of delivery. Contact us first and we'll take it from there.

Ships within 24 hours!

Ships within 24 hours basically means that your product will be shipped out or dispatched from our warehouse within 24 hours if it has enough stock. Read more.

Choose a Local Warehouse, Get More Benefits!

UK customers: choose the UK warehouse for faster delivery, easier after-sales support and no customs clearance. The China warehouse is open to all countries.

This 90x90mm hollow shaft single-phase AC motor with adjustable speed control is operated with 220VAC. It has a speed range of 3-45rpm and a right angle gearbox with a gear ratio of 30. The right angle gearboxes are compact in size, run smoothly and can handle high torques. The simple brushless structure, high reliability, relatively high efficiency and long service life make it an excellent cost-effective choice for constant speed applications like industrial equipments, household appliances, power supply systems, transportation, mechanical equipment, etc.

Electrical Specifications

P/N: 5IK120RGU-CF/5GU30RC
Gearbox Type: Right Angle Gearbox
Output Power: 120W
Voltage: 1PH 220VAC
Frequency: 50Hz
Current: 0.87A
Gear Ratio: 30:1
Speed Range: 3-45rpm
Maximum Torque: 19.00Nm(2690.59oz.in)
Capacitor: 6.0μF/450VAC

Physical Specifications

Frame Size: 90x90mm
Body Length: 289mm
Shaft Type: Hollow
Bore Diameter: Φ17mm
Weight: 6.5kg

Wiring

Electrical Specification
Current(A)	0.87
Frequency(Hz)	50
Input Voltage(V)	1PH 220VAC
Max. Torque(Nm)	19.00
Output Power(W)	120
Speed Range(rpm)	3-45
Physical Specification
Frame Size(mm)	90 x 90
Gear Ratio(xx:1)	30
Gearbox Type	Right Angle Gearbox
Output Shaft Type	Hollow
